NASA/JPL/Malin Space Science Systems

This Mars Global Surveyor (MGS) Mars Orbiter Camera (MOC) image was acquired using the cPROTO technique described on 27 September 2004 in "cPROTO Views of Spirit's Rover Tracks and Athabasca Vallis Flood Features." In other words, the picture was obtained by MOC with a resolution that is better than 1 meter per pixel (better than 3 feet per pixel). On the left is a view of the entire cPROTO image; on the right is a magnified view of the features seen in the white box on the left. The 200 meter scale bar is about 219 yards long. This cPROTO image, obtained in August 2004, shows layered sedimentary rocks exposed in eastern Candor Chasma, part of the vast Valles Marineris trough system. On the steep slope in the lower half of the image (left), the rocks have been breaking down into fine-grained material that slides down the slope to create fan-shaped talus accumulations. In some cases, the movement of this dry debris has cut narrow, straight chutes into the slope. The sub-meter resolution of the cPROTO image reveals that there are no boulders in the talus, attesting to the extremely fine-grained and easily broken-up nature of these sedimentary rocks. The image is located near 7.3°S, 69.0°W. Sunlight illuminates the scene from the upper left.

Malin Space Science Systems and the California Institute of Technology built the MOC using spare hardware from the Mars Observer mission. MSSS operates the camera from its facilities in San Diego, California. The Jet Propulsion Laboratory's Mars Surveyor Operations Project operates the Mars Global Surveyor spacecraft with its industrial partner, Lockheed Martin Astronautics, from facilities in Pasadena, California and Denver, Colorado.
