Overnight on October 4-5, 2012, a mass of energetic particles from the atmosphere of the Sun were flung out into space, a phenomenon known as a coronal mass ejection. Three days later, the storm from the Sun stirred up the magnetic field around Earth and produced gorgeous displays of northern lights. NASA satellites track such storms from their origin to their crossing of interplanetary space to their arrival in the atmosphere of Earth.
Using the "day-night band" (DNB) of the Visible Infrared Imaging Radiometer Suite (VIIRS), the Suomi National Polar-orbiting Partnership (Suomi NPP) satellite acquired this view of the aurora borealis early on the morning of October 8, 2012. The northern lights stretch across Canada's Quebec and Ontario provinces in the image, and are part of the auroral oval that expanded to middle latitudes because of a geomagnetic storm.
The DNB sensor detects dim light signals such as auroras, airglow, gas flares, city lights, and reflected moonlight. In the case of the image above, the sensor detected the visible light emissions as energetic particles rained down from Earth's magnetosphere and into the gases of the upper atmosphere. The images are similar to those collected by the Operational Linescan System flown on U.S. Defense Meteorological Satellite Program (DMSP) satellites for the past three decades.
"When I first saw images like this as a graduate student, I was immediately struck by the fluid dynamic characteristics of the aurora," said Tom Moore, a space physicist at NASA's Goddard Space Flight Center. "Viewing the aurora in this way makes it immediately clear that space weather is an interaction of fluids from the Sun with those of the Earth's upper atmosphere. The electrodynamics make for important differences between plasmas and ordinary fluids, but familiar behaviors (for example, waves and vortices) are still very apparent. It makes me wonder at the ability of apparently empty space to behave like a fluid."
Auroras typically occur when solar flares and coronal mass ejections--or even an active solar wind stream--disturb and distort the magnetosphere, the cocoon of space protected by Earth's magnetic field. The collision of solar particles and pressure into our planet's magnetosphere accelerates particles trapped in the space around Earth (such as in the radiation belts). Those particles are sent crashing down into Earth's upper atmosphere--at altitudes of 100 to 400 kilometers (60 to 250 miles)--where they excite oxygen and nitrogen molecules and release photons of light. The results are rays, sheets, and curtains of dancing light in the sky.
Auroras are a beautiful expression of the connection between Sun and Earth, but not all of the connections are benign. Auroras are connected to geomagnetic storms, which can distort radio communications (particularly high frequencies), disrupt electric power systems on the ground, and give slight but detectable doses of radiation to flight crews and passengers on high-latitude airplane flights and on spacecraft.
The advantage of images like those from VIIRS and DMSP is resolution, according to space physicist Patrick Newell of the Johns Hopkins University Applied Physics Laboratory. "You can see very fine detail in the aurora because of the low altitude and the high resolution of the camera," he said. Most aurora scientists prefer to use images from missions dedicated to aurora studies (such as Polar, IMAGE, and ground-based imagers), which can offer many more images of a storm (rather than one per orbit) and can allow researchers to calculate the energy moving through the atmosphere. There are no science satellites flying right now that provide such a view, though astronauts regularly photograph and film auroras from the International Space Station.
Cooperative Institute for Meteorological Satellite Studies, University of Wisconsin-Madison (2012, September 3) Aurora borealis across Canada on VIIRS Day/Night Band imagery. Accessed October 9, 2012.
Earth Science Picture of the Day (2002, January 30) Aurora Observed from Satellite. Accessed October 9, 2012.
Miller, Steven D. et al (2012, September 25) Suomi satellite brings to light a unique frontier of nighttime environmental sensing capabilities. Proceedings of the National Academy of Sciences, Volume 109, Number 39, 15706-15711.
NASA (2002) Aurora: fabled glowing lights of the Sun-Earth Connection. (PDF) Accessed October 9, 2012.
NASA Earth Observatory (2012, July 26) The Lights of London.
NASA Earth Observatory (2011, September 27) Fires in the Sky and On the Ground.
NASA Earth Observatory image by Jesse Allen and Robert Simmon, using VIIRS Day-Night Band data from the Suomi National Polar-orbiting Partnership (Suomi NPP) and the University of Wisconsin's Community Satellite Processing Package. Suomi NPP is the result of a partnership between NASA, the National Oceanic and Atmospheric Administration, and the Department of Defense. Caption by Mike Carlowicz.
Instrument: Suomi NPP - VIIRS
