Image Context:

These layered deposits are located on the floor of a large canyon called Ganges Chasma which is a part of the Valles Marineris. Dramatic layering can be seen throughout the deposit. Different styles of erosion are manifest in these different layers and at different locations within the layered material. For example, the southern portion of these deposits have a pronounced fluting, whereas in other areas the same layers are more intact. Relatively dark dunes and sand sheets can be observed surrounding the relatively brighter layered material in the upper right and lower portions of the image. Darker material also appears to mantle select areas of the layered deposits. The formation of the dunes is influenced by topography; this influence is best illustrated in the upper left of the image where a small hillock has interfered with the local wind flow. Impact craters of all sizes are noticeably absent in this image, indicating a relatively young age for this surface. This image is approximately 22 km wide and 60 km in length; north is toward the top.

Note: This image has not been radiometrically nor geometrically calibrated for this preliminary release. An empirical correction has been performed to remove instrumental effects. A linear shift has been applied in the cross-track and down-track direction to approximate spacecraft and planetary motion. Fully calibrated and geometrically projected images will be released through the Planetary Data System in accordance with Project policies at a later time.

NASA's Jet Propulsion Laboratory manages the 2001 Mars Odyssey mission for NASA's Office of Space Science, Washington, D.C. The Thermal Emission Imaging System (THEMIS) was developed by Arizona State University, Tempe, in collaboration with Raytheon Santa Barbara Remote Sensing. The THEMIS investigation is led by Dr. Philip Christensen at Arizona State University. Lockheed Martin Astronautics, Denver, is the prime contractor for the Odyssey project, and developed and built the orbiter. Mission operations are conducted jointly from Lockheed Martin and from JPL, a division of the California Institute of Technology in Pasadena.

Image Credit: NASA/JPL/Arizona State University
